Figure 7. Morphological observation of apoptosis of human lung cancer cell line A549 treated with doxorubicin (Dx) and polyphenol (E8) after 1 day of treatment. Red arrowheads indicate apoptotic cell death and yellow arrowheads indicate cell cycle arrest at G2/M metaphase. The percentage of cell viability of apoptotic A549 cells was estimated at 1, 5, 10, 20 µg/ml concentration of E8. The calculated IC₅₀ was found to be 160µg/ml

From

Non-flavonoid Polyphenol of Allium cepa Tuber Inhibits Bacterial Urease and the Proliferation of Lung Cancer Cells

Saadullah, Aziza Sultana, Md. Najem Uddin, Md. Atikur Rahman, Most. Reshma Akter, Ismot Ara Shathi, Mst. Bobita Yeasmin, Md. Mahadi Hasan Lavlu, Monika Rani Saha, Aktar Uzzaman Chouduri
