Pot Experiment: To Study the Uptake of Zinc by Different Plant Species in Artificially Contaminated Soil
1Department of Environmental Sciences, Acharya Nagarjuna University, Nagarjuna Nager, Guntur (Dist.) Andhra Pradesh, India
2Department of Chemistry, University of Toronto, Ontario, Canada
A novel, cost-effective and eco-friendly technologies are needed to remove Zinc from the contaminated soil environment. The present research study was designed to assess the naturally enhanced phyto extraction and phyto stabilization potential of different plant species from the Zinc (II) contaminated soil. Uptake of Zinc by plant species in a metal contaminated soil was studied in pot culture experiment. The pots were filed with 5 kg of garden soil. Weed plants were grown in pots and were irrigated with known heavy metal solutions in the concentration of 5ppm heavy metal Zinc solution was added to the pots alternate days up to 60 days. In controls normal water was used. The plants were grown for a period of 60 days. The initial soil heavy metal concentration was analyzed. After 20, 40 and 60 days soil heavy metal concentrations were also analyzed. Analysis of heavy metal was done in HNO3/HClO4 digested samples by Atomic Absorption spectrophotometer. The plant species had accumulated quantities of heavy metals per Kg of biomass. The plant species showed relatively good response to the higher level of heavy metal concentration in the roots, stem and leafs suggested that these plant species were good metal excluder with the possibility of extracting (Zn) from artificially contaminated soils.
At a glance: Figures
Keywords: pot culture experiment, contaminated soil, phyto remediation, zinc, plant species
World Journal of Environmental Engineering, 2013 1 (2),
Received July 27, 2013; Revised November 14, 2013; Accepted December 11, 2013Copyright: © 2013 Science and Education Publishing. All Rights Reserved.
Cite this article:
- Subhashini, V., A.V.V.S. Swamy, and R. Hema Krishna. "Pot Experiment: To Study the Uptake of Zinc by Different Plant Species in Artificially Contaminated Soil." World Journal of Environmental Engineering 1.2 (2013): 27-33.
- Subhashini, V. , Swamy, A. , & Krishna, R. H. (2013). Pot Experiment: To Study the Uptake of Zinc by Different Plant Species in Artificially Contaminated Soil. World Journal of Environmental Engineering, 1(2), 27-33.
- Subhashini, V., A.V.V.S. Swamy, and R. Hema Krishna. "Pot Experiment: To Study the Uptake of Zinc by Different Plant Species in Artificially Contaminated Soil." World Journal of Environmental Engineering 1, no. 2 (2013): 27-33.
|Import into BibTeX||Import into EndNote||Import into RefMan||Import into RefWorks|
Heavy metals are conventionally defined as elements with metallic properties (ductility, conductivity, stability as cations, ligand specificity, etc.) and atomic number >20. The most common heavy metal contaminants are: Cd, Cr, Cu, Hg, Pb, and Zn. Metals are natural components in soil. Contamination, however, has resulted from the rapidly expanding industrial areas, mine tailings, disposal of high metal wastes, leaded gasoline and paints, land application of fertilizers, animal manures, sewage sludge, pesticides, wastewater irrigation, coal combustion residues, spillage of petrochemicals, and atmospheric deposition [1, 2, 3]. Heavy metals constitute an ill-defined group of inorganic chemical hazards, and those most commonly found at contaminated sites are lead (Pb), chromium (Cr), arsenic (As), zinc (Zn), cadmium (Cd), copper (Cu), mercury (Hg), and nickel (Ni). Soils are the major sink for heavy metals released into the environment by aforementioned anthropogenic activities and unlike organic contaminants which are oxidized to carbon (IV) oxide by microbial action, most metals do not undergo microbial or chemical degradation and their total concentration in soils persists for a long time after their introduction . Changes in their chemical forms (speciation) and bioavailability are, however, possible. The presence of toxic metals in soil can severely inhibit the biodegradation of organic contaminants. Heavy metal contamination of soil may pose risks and hazards to humans and the ecosystem through: direct ingestion or contact with contaminated soil, the food chain (soil-plant-human or soil-plant-animal-human), drinking of contaminated ground water, reduction in food quality (safety and marketability) via phyto toxicity, reduction in land usability for agricultural production causing food insecurity, and land tenure problems . The adequate protection and restoration of soil ecosystems contaminated by heavy metals require their characterization and remediation. Contemporary legislation respecting environmental protection and public health, at both national and international levels, are based on data that characterize chemical properties of environmental phenomena, especially those that reside in our food chain. While soil characterization would provide an insight into heavy metal speciation and bioavailability, attempt at remediation of heavy metal contaminated soils would entail knowledge of the source of contamination, basic chemistry, and environmental and associated health effects (risks) of these heavy metals. Risk assessment is an effective scientific tool which enables decision makers to manage sites so contaminated in a cost-effective manner while preserving public and ecosystem health . Immobilization, soil washing, and Phyto remediation techniques are frequently listed among the best demonstrated available technologies (BDATs) for remediation of heavy metal-contaminated sites . In spite of their cost effectiveness and environment friendliness, field applications of these technologies have only been reported in developed countries. In most developing countries, these are yet to become commercially available technologies possibly due to the inadequate awareness of their inherent advantages and principles of operation. With greater awareness by the governments and the public of the implications of contaminated soils on human and animal health, there has been increasing interest amongst the scientific community in the development of technologies to remediate contaminated sites . Phyto remediation of soil has attracted much attention in recent years due to its multiple advantages such as maintaining the biological activity and physical structure of soils, being potentially inexpensive and visually unobtrusive, and providing the possibility of bio recovery of metals. Identification of native species for Phyto remediation is a key to the success of the method. Keeping in view the heavy metals exposure to the soil environments, this study was planned under green house conditions with the objectives to evaluate the efficacy of different plant species in the uptake and translocation of Zinc (Zn) from the artificially contaminated soils.
2. Materials and Methods2.1. Study Aea and Selection of Pant Secies
In this study ten plant varieties were selected for their ability to absorb heavy metal (Zn) from the contaminated soil. The experimental plants were four weed species, three flowering plants, three grass varieties. The used plant species were 1.Weed species were; Acalyphaindica, Abutilonindicum, Physalisminima and Cleome viscose. 2. Flowering plants were; Catharanthus roseus, Ruallia tuberose, and Canna indica. 3. Grass species were; Perotis indica, Echinocloa colona and Cyperus rotundus . The plant species are selected for the present study because of the qualities, such as large biomass production, perennial, robust rhizomes these are suitable for accumulation of heavy metals.
Fresh plant samples were collected in the morning by pulling carefully from the soil to avoid damage to the roots. samples were collected from the surface to subsurface portion of the soil around the plant roots at a range interval of 20 to 30 square meters apart.2.3. Washing of Plant Samples
The collected samples were washed with distilled water remove dust particles. The samples were then cut to separate the roots, stems and leaves. The different parts (roots, stems and leaves) were air dried and then placed in a de hydrator for 2-3 days and then dried in an oven at 100 °C. Dried samples of different parts of the plants were ground into a fine powder using pestle and mortar and stored in polyethylene bags, until used for acid digestion. Before the experiment soil parameters were done and for every 20 days the soil samples were also collected and analysed for heavy metals by Atomic Absorption Spectrophotometer (make: Schimarze 6800).2.4. Preparation of Plant Samples by Wet Digestion
Samples (0.5g) of each part (leaves, stems and roots) of the plant were weighed in digestion flasks and treated with 5 ml of concentrated HNO3. A blank sample was prepared applying 5ml of HNO3 into empty digestion flask. The flasks were heated for 2 hours on an electric hot plate at 80-90°C at which the samples were made to boil and digestion continued until a clean solution was obtained. After cooling, the solution was filtered with what man No.42 filter paper. It was then transferred quantitatively to a-25ml volumetric flask by adding distilled water. The filtrate was analyzed for metal content using Atomic Absorption spectrophotometer (make: Schimarze 6800).2.5. Preparation of Standards and Analysis of Samples
Standard solution Zinc (Zn) was prepared from the stock standard solution containing 1000 ppm of element in2N nitric acid. Calibration and measurements of elements were done on atomic absorption spectrophotometer (make: Schimarze 6800). The calibration curves were prepared for this element individually. A blank reading was also taken and necessary correction was made during the calculation of concentration of various elements.2.6. Pot Culture Experiment
Uptake of heavy metals by plants in a metal contaminated and normal soil was studied in pot culture experiment. Weed plants, flowering plants and grass species were grown in pots and were irrigated with known heavy metal solutions in the concentration of 5ppm heavy metal solution Zinc (Zn) was added to the pots alternate days up to 60 days. In controls normal water was used. The plants were grown for a period of two months (60days). The contaminated soil received the metals Zn as Zn (NO3)2 3H2O. The initial soil heavy metal concentration was analyzed. After 20, 40 and 60 days soil heavy metal concentrations was analyzed. Every 20 days the plant samples from each pot were collected and washed thoroughly under running tap water and distilled water so that no soil particles remained. Analysis of heavy metals was done in HNO3/HClO4 digested samples  and analyzed by Atomic Absorption spectrophotometer (make: Schimarze 6800). The experiment was carried out in the garden by using heavy metal solutions. The plant sample was uniform in size and which were free of disease symptoms. The pots were filed with 5 kg of garden soil. The plants were watered once every day and care was taken to avoid leaching of water from the pots. After 20 days from each pot plant samples were collected. The plants were harvested after 20 days, 40 days and 60 days for heavy metal analysis.2.7. Statistical Analysis
Average data uptake, transfer coefficient were submitted for statistical analysis. The uptake and mobilization of potentially toxic metals (PTM) in plant tissues were assessed by bioaccumulation coefficient (BC). Differences in heavy metal concentrations among different parts of the weeds were detected using One-way ANOVA, followed by multiple comparisons using Turkey tests. A significance level of (p < 0.05) was used throughout the study. All statistical analyses were performed using STATISTICA (Version 7), MSEXCEL (Microsoft office 2012) and GrphPad Prism (Version 5).
3. Results and Discussion3.1. Physico-chemical Properties of Soil
The results obtained from the soil analysis were shown in Table 1. Soil particle size was determined using Bouyoucos hydrometer method. All reagents used were of analytical grade (BDH Laboratory supplies, Poole, England) The soil pH was determined in a mixture of soil and deionized water (1:2, w/v) with a glass electrode . Total organic carbon content was determined using the Walkey-Black wet oxidation , Total Nitrogen was determined using the Kjeldhal method . Cation exchange capacity (CEC) and amounts of exchangeable Ca and Mg were determined using the ammonium acetate method . Total phosphorus was determined calorimetrically. Total background cadmium concentration was determined using Atomic Absorption Spectrophotometer (make: Schimarze 6800). The electrical conductivity (EC) was measured by using digital meters (Elico, Model LI-120) with a combination of 1-cm platinum conductivity cell.
The taxonomic classification of the experimental soil (Table 1) was sandy loam with pH of 6.94, EC of 455 mS/cm. The high pH level of the soil is generally within the range for soil in the region; soil pH plays an important role in the sorption of heavy metals, it controls the solubility and hydrolysis of metal hydroxides, carbonates and phosphates and also influences ion-pair formation, solubility of organic matter, as well as surface charge of Fe, Mn and Al-oxides, organic matter and clay edges .3.2. Experimental Procedure
The experimental plants were intended to grow for 2 months (60 days) in the soil. The pots used for the experiment contained 5kg of soil. The seedlings of the experimental plants were collected from the uncontaminated soils. In each pot eight seedlings were planted. Grass species were also used for heavy metal accumulation. The plant species used for heavy metal accumulation are tabulated in Table-3.The total experimental period 60 days was divided into 3 stages. The first 20 days period was regarded as I stage. The next 40 days period regarded as II stage. The total 60 days period regarded as III stage. Zinc (Zn) total accumulation values in selected plants were shown in Table 2.
In the first stage: 5ppm /1000ml of Zn, solution was added alternate days to the all pots. The plants were growing. After 20 days two plants were collected from each pot and soil samples were also collected. The collected plant samples were separated into roots, stem and leaves. These are air dried first for two days, and then dried in hot air oven at 101°C for 12 hours. After the plant parts are powdered using mortar and pistle. Then 2g of the root leaves and stem powders are weighed and stored in polyethylene small bags for heavy metal analysis by Atomic Absorption Spectrometer. In the second stage: After 20 days 5ppm/1000ml of heavy metal Zinc (Zn) solutions was added alternate days to the all pots. The plants were growing. In these days the plants growth and physical changes were noted. After 40 days two plants from each pot were collected and soil sample was taken for heavy metal analysis. The collected plant samples plant parts were separated and dried in hot air oven at 101°C for 12 hours. After the plant parts are powdered using mortar and pastel, then 2g of the root stem and leaves powders are weighed and stored in polyethylene bags for heavy metal analysis. In the third stage After 40 days the heavy metal concentrations was increased. 5ppm/1000ml of heavy metal Zinc (Zn) solution was added alternate days to the all plots. The plants were growing. In all these days growth, development and physical characters were recorded. After 60 days two plants from each pot was collected for heavy metal analysis. The soil samples were also collected from each pot for heavy metal analysis. The collected plant samples the plant parts were separated into root, stem and leaves. These are air dried 24hours and then dried in the hot air oven at 101°C for 12 hours. After the plant parts are powered using mortar and pistle.2g of the plant material was weighed and stored in small polyethylene bags for heavy metal analysis by AAS. In the third stage the collected soil samples were also measured for heavy metal analysis. All these stages all the plants were grown in identical environmental conditions. The experimental plants were four weed species, three flowering plants, three grass varieties. Generally grass species does not having stem and leaves except roots, hence we considered root analysis in grass varieties. Zinc (Zn) total accumulation values in selected plants were shown in (Figure 1).
3.3.1. Accumulation Factor (AF)
plants divided into three categories i.e. accumulator, excluder and indicator . In accumulator plants the concentration ratio of the element in the plant to that in the soil is >1. In excluder plant metal concentrations in aerial parts are maintained low (<< 1 ) and constant over a wide range of soil concentrations. In indicator plants the uptake and transport of metals were regulated in such a way that the ratio of the concentration of element in the plant to that in the soil is near 1.As total heavy metal concentration of soils is poor indicator of metal availability for plant uptake, accumulation factor was calculated based on metal availability and its uptake by a particular plant were shown in Table 3. Accumulation Factor for plants was calculated as:
Based on the zinc total accumulation standard deviation values , the selected plants were good accumulators because the concentration ratio of the element in the plant to that in the soil is >1.
3.3.2. Translocation Factor (TF)
Translocation factor is a measure of the ability of plants to transfer accumulated metals from the roots to the shoots. It is given by the ratio of concentration of metal in the shoot to that in the roots .
TFs were also varied under different zinc concentrations in the growth media and a significant difference (p≤0.05) observed among treatments in TFs. This index was in the range of 0.27 to 0.9885 shown in Table.4. It was observed that TFs increased with increase in the applied zinc concentration in the growth media. However, the TFs under different zinc levels were <1 in Acalyphaindica, and Physalisminima, indicating that all plant species were less able to tanslocate Zinc from the roots to the shoots efficiently thus labeling these plants as trace metal excluders. The uptake and transport of metals were regulated in such a way that the ratio of the concentration of element in the plant to that in the soil is near 1 in Cannaindica so labeling of this plant as metal indicator ,where as Abutilonindicum, Cleomeviscosa, Catharanthus roseus, and Ruelliatuberosa were only tanslocate zinc from the roots to the shoots efficiently hence it is considered as accumulator plant (Zn levels was >1 ) .The translocation of Zn is often restricted due to the ability of this element to create Zn-phyto chelatin complex by sequestration in the vacuole . Zn movement from root to shoots probably occurs within the xylem. The levels of free Zn in the symplast can be influenced highly by cellular sequestration of Zn and therefore it can affect the movement of Zn throughout the plants .
3.3.3 Bio Concentration Factor(BCF)
Bioconcentration factor (BCF) is defined as the ratio of heavy metal concentration in plant roots to that in soil . Bioconcentration factor (BCF) was used to evaluate the efficiency of Zn phyto extraction and was calculated using the following Equation:
The BCFs were varied under different Zinc concentrations in the soil and it was in the range of 1.0642 to 21.2518 has shown in Table.5. There was a significant difference (p≤0.05) among treatments in BCFs. The highest BCF (that is 21.2518 ± 0.050) of Zinc was found in Abutilonindicum as compared to other treatment levels. The BCFs were >1 under various treatment levels. The BCFs decreased with increase in the Zinc concentration in the growth media, which may indicate the restriction in soil-root transfer at higher Zinc concentrations in the soil .
3.3.4 Relation between Translocation Factor and Bio Concentration Factor
phyto stabilization, metal-tolerant plants are used to reduce the mobility of metals, thus, the metals are stabilized in the substrate  Plants with both Bioconcentration factor and translocation factor greater than one (TF and BCF > 1) have the potential to be used in phyto extraction. Hence Abutilon indicum, Cleome viscosa, Catharanthus roseus,and Ruellia tuberosa have the potential to be used in phyto extraction. Acalypha indica, Physalisminima and Canna indica have the potential for phyto stabilization because plants with bioconcentration factor greater than one and translocation factor less than one (BCF > 1 and TF < 1) have the potential for phyto stabilization. Perotisindica, Echinocloacolona and Cyperusrotundus were good metal accumulators because in accumulator plants the concentration ratio of the element in the plant to that in the soil is >1. By comparing BCF and TF, the ability of different plants in taking up metals from soils and translocating them to the shoots can be compared. As shown in Table 4 and Table 5, among the sampled plants, like Abutilo indicum, Cleomeviscosa Catharanthus roseus, and Ruelliatuberosa were suitable for phyto extraction of Zn-metal where as plants like Acalyphaindica, Physalisminima and Cannaindica were most suitable for phyto stabilization.
Metal-contaminated soils are notoriously hard to remediate. Current technologies resort to soil excavation and either land filling or soil washing followed by physical or chemical separation of the contaminants. Because of the high cost, there is a need for less-expensive cleanup technologies. Phyto remediation is an effective and affordable technology used to remove inactive metals and metal pollutants from contaminated soil and water. It includes phyto extraction, phyto stabilization, phyto volatization, and phyto degradation/ phyto transformation. In this research the accumulated toxic metal (Zn) concentration in roots, stems and leafs, growing conditions, and their economic values were three major factors for selecting the plants. According to pot experiments results the selected plants were good accumulators because the concentration ratio of the element in the plant to that in the soil is >1. Among the 10 sampled plant species, Abutilon indicum, Cleome viscosa, Catharanthus roseus and Ruellia tuberosa, Perotisindica, Echinocloacolona and Cyperusrotundus have the potential to be used in phyto extraction (TF and BCF>1). Acalypha indica, Physalisminima and Canna indica have the potential for phyto stabilization (TF<1 and BCF>1).The results of this study are of considerable significance in demonstrating the practical application of selected plants for Phyto remediation of Zn-polluted soil although further research on their relevant mechanisms are very much required. Extensive research was in progress in Department of Environmental sciences, Acharya Nagarjuna University, India, regarding the results obtained from Pot experiments like Physico-chemical properties of Soil, Metal transfer co-efficients in the direction of pilot- scale reactor operation for removal of heavy metals from the aqueous solutions and contaminated soils.
The authors would like to thank to Prof. Z. Vishnuvardhan, Dean and Board of the Studies, Department of environmental sciences Acharya Nagarjuna University, India, for his cooperation and encouragement. Our special thanks also reserved for our family members and friends who stand always by our side in all our endeavors.
The authors declare that they have no competing interests.
