Figure 1. The radiological results of introduction of metal screw implants with various character of a surface into rabbits’ tibial proximal condyle. a - In 2 months after introduction the implant with a rough surface is located in a condyle of a tibial bone, there is a periosteum thickening in the field of a product head. b - 2 months later after surgical intervention the polished implant is present in a condyle of a tibial bone where there is a periosteum thickening. c - After removal of rough implant 6 months later in a bone tissue there are sites of the reduced density according to an arrangement of a screw thread sides, the increase of bone density is noted only in external areas of a condyle where the product is established. d - After removal of smooth implants in 6 months after operation in a bone there are depression sites corresponding to an arrangement of sides of a product, the increase in density of bone is noted only in periostum areas where the head and the end of an implant are located

From

Changes of the Surfaces of Various Metal Implants after Introduction into Rabbits’ Bone Tissue

M.S. Toder, A.I. Shevela, A.A. Shevela, P.A. Zheleznyi, A.P. Zheleznaia, I.V. Mayborodin
