Figure 12. Block diagram of HF unique double bridge LCL resonant inverter to combine a dc supply along one phase line. [14]

From

Multi-input Single Stage Three Port DC-AC Converters in Renewable Energy Applications – An Overview

Md. Maidul Islam, Minhaz Uddin, Mst.Iffatara Shanu, Faria Akter, Md Sazal Miah

American Journal of Electrical and Electronic Engineering. 2023, 11(1), 7-12 doi:10.12691/ajeee-11-1-2
